DPSS 532nm Single Longitude Mode Green Laser
Specifications:
Model
SDL-532-SLM-XXXT
Output Power @ 25 ¡æ
1~100mW
Wavelength
532nm
Operation Mode
CW
Longitudinal mode
Single
Transverse mode
TEM00
Beam height from base plate (mm)
24. 8mm
Linear Polarization
>50:1(45 degree)
Beam Diameter at the aperture
~2. 0mm
Beam Divergence (1/e2, Full Angle)
<1.5mrad
Power Stability after warm-up
<1%, <3%, <5% (over 2/4/8 hours)
M2 factor
<1.2mm
Warm-up time
<15 minutes
Dimension of laser head
142 x 73 x 46mm
Power Supply
PS-300
Input Voltage
90-264VAC, 50/60Hz
Coherent length (m)
>50M
Dimension of Power Suply
130 x 120 x 62mm
Operating Temperature
10¡æ¡«35¡æ
Expect life time
10000 hours
Warranty time
1 year
Note:
See the Glossary and Technology for information about the terms used
In the front of the laser, we add an infrared filter. The residual IR part is less than 10-3. Please refer to the technology page for more information about the filter.
Other Sytles and custom designs are available. Contact us to discuss your needs.
